MWalloys manufactures a comprehensive range of alloy plates, including nickel‑based (Inconel 625, Incoloy 800, Hastelloy C‑276), stainless steel (304, 316L, 321, 904L), duplex & super‑duplex (2205, 2507), titanium (Ti‑6Al‑4V, CP‑Grade 2), aluminum (6061, 7075) and carbon steel (A36, A106) in various thicknesses, lengths, and widths. Our alloy plates are ideal for applications in industries such as aerospace, chemical processing, oil & gas, power generation, and marine environments, providing superior performance in high‑stress, high‑temperature, and corrosive conditions.
Full Specifications & Parameters
| Alloy Grade | Chem. Composition (%)** | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Thickness Range (mm) | Width Range (mm) | Length Range (mm) | Weight (kg/m²)* | Common Applications |
|---|---|---|---|---|---|---|---|---|---|
| Inconel 625 | Ni 58–63, Cr 20–23, Mo 8–10, Fe ≤5 | 586–827 | ≥241 | ≥30 | 3–150 | 1000–2500 | 1000–12000 | 8–220 | Aerospace, power generation |
| Hastelloy C‑276 | Ni Balance, Cr 14.5–16.5, Mo 15–17, Fe ≤4 | 586–862 | ≥241 | ≥35 | 3–150 | 1000–2500 | 1000–12000 | 10–230 | Chemical processing, marine |
| 304 Stainless | Fe Balance, Cr 18–20, Ni 8–10.5, C ≤0.08 | 515–720 | ≥205 | ≥40 | 1.5–200 | 1000–2500 | 1000–12000 | 8–200 | Food, pharmaceutical, general use |
| 316L Stainless | Fe Balance, Cr 16–18, Ni 10–14, Mo 2–3 | 515–690 | ≥205 | ≥40 | 1.5–200 | 1000–2500 | 1000–12000 | 9–210 | Marine, pharmaceutical, chemical |
| Duplex 2205 | Fe Balance, Cr 22–23, Ni 4.5–6.5, Mo 2.5–3.5 | 620–860 | ≥450 | ≥25 | 3–100 | 1000–2500 | 1000–12000 | 10–250 | Oil & gas, pulp & paper |
| Ti‑6Al‑4V | Ti Balance, Al 5.5–6.75, V 3.5–4.5 | 895–965 | 830–895 | ≥10 | 1.5–50 | 1000–2500 | 1000–12000 | 7–180 | Aerospace, medical, military |
| A36 Carbon Steel | C 0.25–0.29, Mn 0.40–1.00, Fe Balance | 400–550 | ≥250 | ≥20 | 6–200 | 1000–2500 | 1000–12000 | 6–180 | Construction, bridges, heavy industry |
* Weight per square meter varies based on thickness, grade, and dimensions.
** Typical ranges; refer to MTR for exact values.
Why Choose MWalloys
-
Comprehensive Alloy Selection: We provide a wide variety of alloys in various thicknesses, suitable for demanding industries like aerospace, energy, and chemicals.
-
Superior Quality Control: Each plate undergoes stringent quality checks, including chemical composition analysis, mechanical testing, and third-party inspections, ensuring top-notch performance.
-
Customization: Custom sizes, finishes, and fabrication services are available to meet specific project requirements.
-
Global Presence: With expertise in global supply, we ship to over 50 countries, ensuring timely delivery and competitive pricing.
-
Technical Support: Our experienced metallurgists and engineers are available for consultation, helping customers select the optimal material for their applications.
Logistics & Ordering
-
MOQ: 100 kg (negotiable for certain alloys and sizes)
-
Lead Time: 2–6 weeks from order confirmation
-
Packaging: Each plate is carefully packaged in seaworthy crates, shrink‑wrapped for protection.
-
Shipping Options: FOB, CIF, EXW, and DDP available. We work with global logistics providers to ensure timely delivery.
-
Order Process:
-
Submit your material grade, size, and quantity to sales@MWalloys.com
-
Receive a quotation and proforma invoice, confirming payment terms
-
Production and quality inspection, followed by shipment and tracking updates
-
FAQs
| Q | A |
|---|---|
| What grades of alloy plates do you supply? | We supply Inconel, Hastelloy, titanium, stainless steel, and carbon steel plates. |
| Do you provide custom sizes and finishes? | Yes, we offer custom sizes, finishes, and fabrication services to meet specific project requirements. |
| What is the lead time for alloy plates? | Typically, 2–6 weeks, depending on material availability and order size. |
| Can you supply plates with certifications? | Yes, all plates come with mill test reports (MTRs), and third-party inspection is available upon request. |
| How do you ensure the quality of the alloy plates? | All plates undergo rigorous quality control, including chemical composition analysis, mechanical testing, and non-destructive testing (NDT). |
| Are your alloy plates suitable for high-temperature applications? | Yes, we provide alloys like Inconel 625 and Hastelloy C-276, specifically designed for high-temperature environments. |
