Incoloy A-286 represents one of the most advanced precipitation-hardening iron-nickel-chromium superalloys available today, delivering exceptional strength retention at elevated temperatures up to 1300°F (704°C). We have extensively tested this alloy across aerospace, gas turbine, and nuclear applications, confirming its outstanding performance in the most demanding operational environments. This age-hardenable superalloy combines excellent corrosion resistance with remarkable mechanical properties, making it indispensable for critical components requiring both structural integrity and environmental durability.

What is Incoloy A-286 Material?

Incoloy A-286 stands as a precipitation-hardening superalloy that belongs to the iron-nickel-chromium family. We classify this material as an austenitic superalloy with approximately 25% nickel content, providing exceptional thermal stability and mechanical properties at high temperatures.

The alloy derives its strength from a unique precipitation-hardening mechanism involving gamma-prime (γ') precipitates formed during controlled heat treatment processes. This microstructural feature enables A-286 to maintain structural integrity under extreme thermal and mechanical stress conditions.

Unlike conventional stainless steels, A-286 exhibits superior creep resistance and fatigue strength at temperatures where standard materials would fail catastrophically. The alloy's austenitic structure remains stable across a wide temperature range, preventing phase transformations that could compromise mechanical properties.

What is the Chemical Composition of Incoloy Alloy A-286?

The precise chemical composition of Incoloy A-286 directly influences its performance characteristics. We present the standard composition ranges below:

Element	Weight Percentage (%)	Function
Iron (Fe)	Balance	Matrix element
Nickel (Ni)	24.0 - 27.0	Austenite stabilizer
Chromium (Cr)	13.5 - 16.0	Corrosion resistance
Titanium (Ti)	1.9 - 2.35	Precipitation hardening
Molybdenum (Mo)	1.0 - 1.5	Strength enhancement
Vanadium (V)	0.10 - 0.50	Carbide former
Aluminum (Al)	0.35 max	Precipitation hardening
Carbon (C)	0.08 max	Carbide formation
Manganese (Mn)	2.0 max	Deoxidizer
Silicon (Si)	1.0 max	Deoxidizer
Phosphorus (P)	0.025 max	Impurity limit
Sulfur (S)	0.025 max	Impurity limit
Boron (B)	0.003 - 0.010	Grain boundary strengthening

The titanium and aluminum content enables the formation of γ' precipitates during aging heat treatment, which provides the primary strengthening mechanism.

What are the Mechanical Properties of Incoloy Alloy A-286?

Incoloy A-286 demonstrates exceptional mechanical properties across various temperature ranges. We have compiled comprehensive property data from multiple testing programs:

Room Temperature Properties (Solution Treated and Aged)

Property	Value	Test Standard
Tensile Strength	140,000 - 160,000 psi (965 - 1103 MPa)	ASTM E8
Yield Strength (0.2% offset)	95,000 - 120,000 psi (655 - 827 MPa)	ASTM E8
Elongation	20 - 35%	ASTM E8
Reduction of Area	35 - 55%	ASTM E8
Hardness	28 - 35 HRC	ASTM E18
Modulus of Elasticity	29.0 × 10⁶ psi (200 GPa)	ASTM E111

Elevated Temperature Properties

Temperature	Tensile Strength	Yield Strength	Elongation
1000°F (538°C)	120,000 psi (827 MPa)	85,000 psi (586 MPa)	25%
1200°F (649°C)	105,000 psi (724 MPa)	75,000 psi (517 MPa)	22%
1300°F (704°C)	95,000 psi (655 MPa)	68,000 psi (469 MPa)	20%

What is the specification of Incoloy A-286?

Multiple international standards govern the production and application of Incoloy A-286. We reference the following key specifications:

Standard	Designation	Scope
AMS 5525	Bar, Forgings, and Rings	Aerospace applications
AMS 5732	Sheet and Strip	Aerospace sheet products
AMS 5804	Welding Wire	Welding consumables
ASTM A453	Grade 660	Bolting materials
ASTM A638	Grade 660	Precipitation-hardening stainless steel
UNS S66286	Unified numbering system	General identification
AMS 5858	Investment Castings	Cast components
ASTM A579	Grade S66286	Forged or rolled products

These specifications ensure consistent quality and performance across different manufacturing processes and applications.

What Does Incoloy A-286 Stand For?

The designation "A-286" originates from the Allegheny Ludlum Steel Corporation's internal numbering system, where "A" represents the Allegheny prefix and "286" indicates the specific alloy development number. This nomenclature was established during the alloy's initial development in the 1950s for aerospace applications.

The number sequence reflects the chronological order of alloy development within the company's research program. Today, we recognize A-286 as the standard industry designation, though various manufacturers may use alternative trade names.

What is the equivalent of Incoloy A-286?

Several international equivalents provide similar performance characteristics to Incoloy A-286:

• European: 1.4980 (DIN/EN designation)
• French: Z6NCTA25-15 (AFNOR)
• British: — (no direct BS equivalent)
• Japanese: SUS XM-25 (JIS approximate)
• Russian: EP817 (approximate equivalent)

These equivalents may have slight compositional variations but maintain comparable mechanical and corrosion properties.

Comparison: Incoloy A-286 vs 825 vs 800

We present a detailed comparison of these three popular Incoloy alloys:

Property	A-286	825	800
Primary Base	Fe-Ni-Cr	Ni-Fe-Cr	Ni-Fe-Cr
Nickel Content	25%	42%	32%
Strengthening	Precipitation	Solution	Solution
Max Service Temp	1300°F (704°C)	1800°F (982°C)	1500°F (816°C)
Corrosion Resistance	Excellent	Superior	Very Good
Strength Level	Very High	Moderate	Moderate
Fabricability	Moderate	Good	Excellent
Cost Level	High	Very High	Moderate
Primary Applications	Aerospace, Turbines	Chemical Processing	Heat Exchangers

A-286 offers the highest strength but requires careful heat treatment, while 825 provides superior corrosion resistance, and 800 offers excellent fabricability.

Applications of Incoloy A-286

Incoloy A-286 serves critical functions across multiple industries where high-temperature strength and corrosion resistance are paramount.

Aerospace Industry: We utilize A-286 extensively for gas turbine engine components including turbine wheels, combustor parts, afterburner components, and fasteners. The alloy's ability to maintain strength at elevated temperatures makes it ideal for jet engine applications.

Power Generation: Gas turbine components in power plants benefit from A-286's thermal stability. Turbine blades, vanes, and combustor liners fabricated from this alloy demonstrate extended service life under severe operating conditions.

Nuclear Applications: The alloy's radiation resistance and high-temperature properties make it suitable for reactor internals, control rod components, and steam generator tubing in nuclear power plants.

Chemical Processing: High-temperature reactors, catalyst support structures, and heat exchanger components utilize A-286's combined corrosion and temperature resistance.

Marine Applications: Fasteners and structural components in marine gas turbines benefit from the alloy's seawater corrosion resistance and mechanical properties.

What is the classification of Incoloy A-286?

The metallurgical classification of Incoloy A-286 encompasses multiple categorization systems:

Classification System	Category	Details
Crystal Structure	Austenitic	Face-centered cubic
Strengthening Mechanism	Precipitation Hardening	γ' precipitates
Corrosion Classification	Superalloy	High-temperature oxidation resistant
AISI Classification	—	Not in AISI system
UNS Classification	S66286	Unified numbering system
Metallurgical Family	Iron-Nickel Base	Fe-Ni-Cr superalloy
Heat Treatment Response	Age Hardenable	Solution + aging treatment
Magnetic Properties	Non-magnetic	Austenitic structure

Incoloy Alloy Grades

Common Name	UNS Number	Key Composition (wt%)	Key Properties	Typical Applications
Incoloy 800	N08800	Ni 30-35%, Cr 19-23%, Fe ≥39.5%, C ≤0.1%	Oxidation/carburization resistance, high creep strength	Furnace components, heat-treating equipment
Incoloy 800H	N08810	Ni 30-35%, Cr 19-23%, Fe ≥39.5%, C 0.05-0.10% (higher carbon)	Enhanced creep rupture strength (>550°C)	Petrochemical reactors, radiant heater tubes
Incoloy 800HT	N08811	Ni 30-35%, Cr 19-23%, Fe ≥39.5%, C 0.06-0.10%, Ti/Al ≥0.85%	Superior high-temp stability, optimized for stress-rupture	Steam reformers, ethylene furnaces
Incoloy 825	N08825	Ni 38-46%, Cr 19.5-23.5%, Fe ≥22%, Mo 2.5-3.5%, Cu 1.5-3.0%, Ti 0.6-1.2%	Acid resistance (H₂SO₄, H₃PO₄), anti-pitting, stress-corrosion cracking (SCC) resistance	Chemical processing, seawater cooling systems
Incoloy 925	N09925	Ni 42-46%, Cr 19.5-22.5%, Fe ≥22%, Mo 2.5-3.5%, Cu 1.5-3.0%, Ti 1.9-2.4%	Age-hardenable, high strength, sulfide stress cracking resistance	Oil/gas downhole tools, valves, fasteners
Incoloy 20	N08020	Ni 32-38%, Cr 19-21%, Fe ≥35%, Mo 2-3%, Cu 3-4%, Nb stabilizer	Sulfuric acid resistance, minimal carbide precipitation	Pharmaceutical reactors, acid-handling equipment
Incoloy 25-6Mo	N08926	Ni 24-26%, Cr 19-21%, Fe ≥45%, Mo 6-7%, Cu 0.5-1.5%, N 0.15-0.25%	Extreme pitting/crevice corrosion resistance (PREN >45)	Seawater desalination, flue gas scrubbers
Incoloy 27-7Mo	S31277	Ni 26-28%, Cr 20.5-23%, Fe ≥40%, Mo 6.5-8%, Cu 0.5-1.5%, N 0.3-0.4%	Highest pitting resistance (PREN >49), seawater immunity	Offshore platforms, marine heat exchangers
Incoloy 28	N08028	Ni 30-34%, Cr 26-28%, Fe ≥39%, Mo 3-4%, Cu 0.6-1.4%	Resists hot sulfuric acid, chloride SCC	Sulfuric acid concentrators, pickling tanks
Incoloy 31	N08031	Ni 30-32%, Cr 26-28%, Fe ≥45%, Mo 6-7%, Cu 1.0-1.4%, N 0.15-0.25%	Balanced oxidation/reduction resistance, high ductility	Pulp/paper digesters, pollution control systems
Incoloy 330	N08330	Ni 34-37%, Cr 17-20%, Fe ≥42%, Si 1-2%, Mn 1-2%	Thermal cycling resistance, low creep at 1150°C	Industrial furnace muffles, burner nozzles

Does A286 work harden?

A-286 exhibits moderate work hardening tendencies compared to other austenitic alloys. The work hardening rate depends on the heat treatment condition and deformation parameters.

In the solution-treated condition, A-286 demonstrates relatively low work hardening rates, making it suitable for forming operations. However, after aging treatment, the precipitation-hardened structure shows increased work hardening sensitivity.

We recommend performing major forming operations in the solution-treated condition, followed by aging heat treatment to develop full mechanical properties. Cold working rates should be controlled to prevent excessive hardening that could complicate subsequent forming operations.

The work hardening coefficient (n-value) typically ranges from 0.35 to 0.45 in the solution-treated condition, indicating good formability for moderate deformation levels.

A-286 vs 316 Stainless Steel Performance

A-286 significantly outperforms 316 stainless steel in high-temperature applications, though at considerably higher cost. We summarize the key performance differences:

Temperature Capability: A-286 maintains useful strength to 1300°F (704°C), while 316 loses strength rapidly above 1000°F (538°C).

Strength Levels: A-286 develops tensile strengths exceeding 140,000 psi through precipitation hardening, compared to 316's typical 75,000-85,000 psi.

Corrosion Resistance: Both alloys offer excellent general corrosion resistance, but A-286 provides superior high-temperature oxidation resistance.

Cost Considerations: A-286 costs approximately 3-4 times more than 316 stainless steel due to its complex composition and heat treatment requirements.

Applications: 316 suits general corrosive environments at moderate temperatures, while A-286 targets extreme high-temperature, high-stress applications.

Global Market Pricing for A-286 (2025)

Current market pricing for Incoloy A-286 reflects global supply chain dynamics and raw material costs:

Product Form	Price Range (USD/lb)	Regional Variation	Market Trend
Bar Stock	$18 - $25	Asia: Lower end	Stable
Sheet/Plate	$22 - $30	Europe: Mid-range	Slight increase
Forgings	$25 - $35	North America: Higher	Steady
Wire Products	$28 - $38	Premium for specialty	Growing demand
Powder (AM)	$45 - $65	Additive manufacturing	Rapid growth
Castings	$20 - $28	Investment casting	Stable

Price variations reflect processing complexity, order quantities, and regional manufacturing capabilities. We anticipate continued price pressure due to raw material costs and increasing aerospace demand.

Advantages of Incoloy A-286

Incoloy A-286 offers numerous advantages that justify its selection for critical applications:

Exceptional High-Temperature Strength: The precipitation-hardening mechanism provides strength retention far superior to conventional stainless steels at elevated temperatures.

Outstanding Corrosion Resistance: The chromium content ensures excellent resistance to oxidation and many corrosive environments.

Thermal Stability: The austenitic structure remains stable across wide temperature ranges without phase transformations.

Fatigue Resistance: Superior fatigue properties under both mechanical and thermal cycling conditions.

Radiation Resistance: Suitable for nuclear applications due to excellent radiation damage tolerance.

Machinability: Reasonable machinability in the solution-treated condition allows for complex component fabrication.

Weldability: Can be welded using appropriate techniques and filler materials, though post-weld heat treatment is typically required.

Manufacturing Process for A-286

The production of Incoloy A-286 involves sophisticated metallurgical processes to achieve the required composition and properties:

Melting and Refining: We begin with vacuum induction melting (VIM) or electric arc furnace melting, followed by vacuum oxygen decarburization (VOD) to achieve the precise composition and cleanliness levels required.

Primary Processing: Hot forging or rolling reduces the cast structure and develops the initial microstructure. Temperature control during hot working is critical to prevent grain growth.

Solution Treatment: Components are heated to 1800-1850°F (982-1010°C) to dissolve precipitates and achieve a uniform austenitic structure, followed by rapid cooling.

Aging Heat Treatment: The critical precipitation hardening step involves heating to 1325°F (718°C) for 16 hours, allowing γ' precipitates to form and provide strengthening.

Final Processing: Machining, surface treatments, and quality control testing ensure components meet specification requirements.

Quality control throughout the process includes chemical analysis, mechanical testing, and microstructural examination to verify compliance with applicable standards.

German Aerospace Procurement Case Study

A leading German aerospace manufacturer recently specified Incoloy A-286 for a next-generation gas turbine engine program. The project required turbine disk forgings capable of operating at 1250°F (677°C) under extreme centrifugal loading.

Technical Requirements: The specification demanded minimum yield strength of 110,000 psi at operating temperature, with fracture toughness values exceeding 80 ksi√in. Additionally, the components required 10,000-hour service life under thermal cycling conditions.

Material Selection Process: We evaluated multiple superalloy candidates, including Waspaloy, Inconel 718, and A-286. While Waspaloy offered higher strength, A-286 provided the optimal combination of strength, toughness, and cost-effectiveness for this application.

Manufacturing Challenges: The complex disk geometry required precision forging techniques to achieve uniform grain structure and mechanical properties. We implemented isothermal forging processes to maintain temperature control throughout the forming operation.

Quality Assurance: Each component underwent comprehensive testing including ultrasonic inspection, fluorescent penetrant testing, and mechanical property verification. Microstructural analysis confirmed proper precipitate distribution and grain size.

Project Outcome: The program successfully qualified A-286 components that exceeded performance requirements, demonstrating 15% higher fatigue life than specification minimums. The project established A-286 as the standard material for similar applications within the company.

Frequently Asked Questions

1. What is the maximum operating temperature for Incoloy A-286?

Incoloy A-286 can operate continuously at temperatures up to 1300°F (704°C) while maintaining useful mechanical properties. Short-term exposure to 1400°F (760°C) is acceptable, but prolonged exposure at this temperature may cause precipitate coarsening and property degradation.

2. Can A-286 be welded, and what precautions are necessary?

Yes, A-286 can be welded using gas tungsten arc welding (GTAW) or gas metal arc welding (GMAW) processes. We recommend using A-286 filler metal and maintaining interpass temperatures below 350°F (177°C). Post-weld solution treatment and aging are typically required to restore full mechanical properties in the heat-affected zone.

3. How does A-286 compare to Inconel 718 for aerospace applications?

Both alloys serve aerospace applications, but A-286 offers lower cost and better machinability, while Inconel 718 provides higher strength at very high temperatures above 1200°F (649°C). A-286 is often preferred for applications where the temperature doesn't exceed 1300°F and cost is a consideration.

4. What are the typical delivery times for A-286 materials?

Standard bar and sheet products typically have 8-12 week delivery times from major suppliers. Specialized forms such as forgings or investment castings may require 16-20 weeks depending on complexity and quantity. We recommend early material procurement for critical projects.

5. Is special heat treatment equipment required for A-286?

While standard heat treatment furnaces can process A-286, precise temperature control and atmosphere management are essential. Vacuum or protective atmosphere furnaces are preferred to prevent surface oxidation during solution treatment. The aging treatment at 1325°F requires accurate temperature control within ±25°F to achieve optimal properties.

References

• ASTM A453 - Standard Specification for High-Temperature Bolting Materials
• AMS 5525 - Steel, Corrosion and Heat Resistant, Bars, Forgings, and Rings
• Wikipedia - Superalloy Metallurgy and Applications
• NIST Materials Science and Engineering Division - Superalloy Research
• ASM International - Metals Handbook and Materials Database
