Incoloy Alloy 800 stands as the industry benchmark for high-temperature oxidation resistance and structural stability in demanding industrial environments. This nickel-iron-chromium superalloy maintains exceptional mechanical properties at elevated temperatures up to 2100°F (1149°C), making it indispensable for heat treatment equipment, furnace components, and petrochemical processing systems. Our extensive experience with this material confirms its unmatched performance in applications where conventional alloys fail to deliver adequate service life.

What is Incoloy 800 Material?

Incoloy 800 represents a carefully engineered austenitic superalloy that combines the strength of iron with the corrosion resistance of nickel and chromium. This alloy belongs to the iron-nickel-chromium family, specifically designed to maintain structural integrity under extreme thermal cycling conditions.

The material exhibits remarkable resistance to oxidation, carburization, and nitridation at elevated temperatures. Unlike many high-temperature alloys, Incoloy 800 maintains its ductility and toughness even after prolonged exposure to thermal stress.

We classify this superalloy as a solution-strengthened material that derives its high-temperature properties from solid solution hardening rather than precipitation hardening. This characteristic provides excellent thermal stability and resistance to metallurgical instability during extended service.

The alloy's austenitic structure remains stable across its entire service temperature range, preventing harmful phase transformations that could compromise mechanical properties or corrosion resistance.

What is the Chemical Composition of Incoloy Alloy 800?

The precise chemical balance in Incoloy 800 determines its exceptional high-temperature performance:

Element	Weight Percentage (%)	Primary Function
Nickel (Ni)	30.0 - 35.0	Austenite stabilization, high-temperature strength
Chromium (Cr)	19.0 - 23.0	Oxidation resistance, scale formation
Iron (Fe)	Balance (39.5 min)	Base element, cost optimization
Carbon (C)	0.10 maximum	Carbide formation, high-temperature strength
Manganese (Mn)	1.50 maximum	Hot workability, sulfur control
Silicon (Si)	1.00 maximum	Deoxidation, scale adherence
Sulfur (S)	0.015 maximum	Hot workability control
Copper (Cu)	0.75 maximum	Trace element control
Aluminum (Al)	0.15 - 0.60	Scale formation, oxidation resistance
Titanium (Ti)	0.15 - 0.60	Grain size control, carbide stabilization

This composition provides optimal balance between high-temperature oxidation resistance, mechanical properties, and manufacturing cost-effectiveness.

What are the Mechanical Properties of Incoloy Alloy 800?

Incoloy 800 demonstrates superior mechanical characteristics across its operating temperature range:

Property	Value	Testing Temperature
Ultimate Tensile Strength	75 ksi (517 MPa) minimum	Room temperature
Yield Strength (0.2% offset)	30 ksi (207 MPa) minimum	Room temperature
Elongation in 2 inches	30% minimum	Room temperature
Reduction of Area	50% minimum	Room temperature
Hardness	150 HRB maximum	Room temperature
Density	0.287 lb/in³ (7.94 g/cm³)	68°F (20°C)
Melting Range	2475-2525°F (1357-1385°C)	Solidus-Liquidus
Specific Heat	0.106 BTU/lb·°F (444 J/kg·K)	68°F (20°C)
Thermal Conductivity	7.4 BTU·ft/hr·ft²·°F (12.8 W/m·K)	68°F (20°C)
Coefficient of Thermal Expansion	8.0 × 10⁻⁶ in/in/°F	68-200°F range

These properties demonstrate the alloy's capability to maintain structural integrity under severe thermal and mechanical loading conditions.

What is the specification of Incoloy Alloy 800?

Incoloy 800 conforms to numerous international standards ensuring quality and performance consistency:

Standard Organization	Specification Number	Product Form Coverage
ASTM International	B163, B407, B408, B409, B514, B515, B564, B751	Tubes, plates, sheets, bars, forgings
ASME Boiler Code	SB-163, SB-407, SB-408, SB-409, SB-514, SB-515, SB-564	Pressure vessel components
Unified Numbering System	N08800	Material identification
German Standard (DIN)	1.4876	European market designation
European Standard (EN)	X10NiCrAlTi32-21	EN 10095 classification
Japanese Industrial Standard	NCF800	JIS G4901 specification
British Standard	HR201	BS 3076 designation
French Standard (AFNOR)	Z15CN24-13	National specification

These comprehensive specifications ensure material traceability and quality assurance across global manufacturing operations.

What does Incoloy 800 stand for?

The "Incoloy 800" designation follows Special Metals Corporation's proprietary naming system for iron-nickel-chromium alloys. "Incoloy" identifies the trademarked family of iron-nickel based superalloys, distinguishing them from the "Inconel" family of primarily nickel-based alloys.

The numerical designation "800" represents the specific composition within the Incoloy family. This number system helps differentiate between various grades such as 800H, 800HT, 801, and 825, each optimized for specific application requirements.

We recognize this designation system as industry standard, facilitating clear communication between suppliers, engineers, and end users worldwide. The systematic approach ensures consistent material properties and performance expectations across different manufacturers.

What is Incoloy Alloy 800 equivalent to?

Multiple international standards recognize equivalent materials to Incoloy 800:

Country/Region	Equivalent Designation	Standard Reference
Germany	1.4876 (X10NiCrAlTi32-21)	DIN 17742
United Kingdom	HR201	BS 3076
France	Z15CN24-13	AFNOR NF A35-590
Japan	NCF800	JIS G4901
China	GH1140	GB/T 14992
Russia	06KhN28MDT	GOST 5632
Sweden	SIS 2328	Swedish standard
Italy	X8NiCrAlTi32-21	UNI 6901
Canada	CSA G40.21 equivalent	Canadian standard

These equivalents maintain similar compositional ranges and performance characteristics, though minor variations may exist in specific element limits.

What is the difference between Incoloy 825 and 800?

The fundamental differences between Incoloy 825 and 800 reflect their distinct application focuses:

Characteristic	Incoloy 800	Incoloy 825
Primary Application	High-temperature oxidation	Corrosion resistance
Maximum Service Temperature	2100°F (1149°C)	1000°F (538°C)
Nickel Content	30-35%	38-46%
Copper Addition	None	1.5-3.0%
Molybdenum Content	None	2.5-3.5%
Aqueous Corrosion Resistance	Limited	Excellent
Chloride Resistance	Poor	Superior
Cost Comparison	Lower	Higher
Thermal Stability	Excellent	Good
Stress Corrosion Cracking	Susceptible	Resistant
Fabrication Complexity	Standard	Standard

This comparison highlights how compositional differences target specific performance requirements in different operating environments.

What is a Incoloy 800 used for?

Incoloy 800 serves critical functions across multiple high-temperature industrial sectors:

Heat Treatment Industry: Furnace components including muffles, radiant tubes, and conveyor systems benefit from the alloy's exceptional oxidation resistance. We observe excellent performance in carburizing and nitriding atmospheres where conventional materials deteriorate rapidly.

Petrochemical Processing: Steam reformer tubes, cracking furnace components, and catalyst support structures utilize Incoloy 800's stability in hydrocarbon environments at elevated temperatures. The material withstands thermal cycling inherent in these processes.

Power Generation: Superheater tubes, steam piping systems, and turbine components in fossil fuel and nuclear power plants rely on this alloy's creep resistance and thermal stability.

Nuclear Applications: Steam generator tubing and reactor internals benefit from the material's resistance to stress corrosion cracking in high-temperature water environments.

Industrial Heating: Electric heating elements, kiln furniture, and thermal processing equipment utilize the alloy's electrical resistivity and thermal shock resistance.

Aerospace Manufacturing: Gas turbine components and exhaust systems in commercial and military aircraft applications demand the high-temperature strength that Incoloy 800 provides.

Classification System for Incoloy 800

The comprehensive classification of Incoloy 800 encompasses multiple technical categories:

Classification Category	Type	Specific Details
Alloy Base	Iron-Nickel-Chromium	Austenitic superalloy
Crystal Structure	Austenitic	Face-centered cubic lattice
Strengthening Mechanism	Solid Solution	No precipitation hardening
Temperature Service	High Temperature	Up to 2100°F (1149°C)
Oxidation Resistance	Excellent	Superior scale formation
Corrosion Classification	Limited Aqueous	Primarily high-temperature service
Magnetic Properties	Non-magnetic	Austenitic structure
Thermal Treatment	Solution Annealed	2000-2100°F (1093-1149°C)
Fabrication Category	Readily Workable	Standard metalworking practices
Weldability Class	Excellent	No preheating required

This systematic classification aids engineers in material selection and application engineering decisions.

 Incoloy Alloy Grades

Common Name	UNS Number	Key Composition (wt%)	Key Properties	Typical Applications
Incoloy 800	N08800	Ni 30-35%, Cr 19-23%, Fe ≥39.5%, C ≤0.1%	Oxidation/carburization resistance, high creep strength	Furnace components, heat-treating equipment
Incoloy 800H	N08810	Ni 30-35%, Cr 19-23%, Fe ≥39.5%, C 0.05-0.10% (higher carbon)	Enhanced creep rupture strength (>550°C)	Petrochemical reactors, radiant heater tubes
Incoloy 800HT	N08811	Ni 30-35%, Cr 19-23%, Fe ≥39.5%, C 0.06-0.10%, Ti/Al ≥0.85%	Superior high-temp stability, optimized for stress-rupture	Steam reformers, ethylene furnaces
Incoloy 825	N08825	Ni 38-46%, Cr 19.5-23.5%, Fe ≥22%, Mo 2.5-3.5%, Cu 1.5-3.0%, Ti 0.6-1.2%	Acid resistance (H₂SO₄, H₃PO₄), anti-pitting, stress-corrosion cracking (SCC) resistance	Chemical processing, seawater cooling systems
Incoloy 925	N09925	Ni 42-46%, Cr 19.5-22.5%, Fe ≥22%, Mo 2.5-3.5%, Cu 1.5-3.0%, Ti 1.9-2.4%	Age-hardenable, high strength, sulfide stress cracking resistance	Oil/gas downhole tools, valves, fasteners
Incoloy 20	N08020	Ni 32-38%, Cr 19-21%, Fe ≥35%, Mo 2-3%, Cu 3-4%, Nb stabilizer	Sulfuric acid resistance, minimal carbide precipitation	Pharmaceutical reactors, acid-handling equipment
Incoloy 25-6Mo	N08926	Ni 24-26%, Cr 19-21%, Fe ≥45%, Mo 6-7%, Cu 0.5-1.5%, N 0.15-0.25%	Extreme pitting/crevice corrosion resistance (PREN >45)	Seawater desalination, flue gas scrubbers
Incoloy 27-7Mo	S31277	Ni 26-28%, Cr 20.5-23%, Fe ≥40%, Mo 6.5-8%, Cu 0.5-1.5%, N 0.3-0.4%	Highest pitting resistance (PREN >49), seawater immunity	Offshore platforms, marine heat exchangers
Incoloy 28	N08028	Ni 30-34%, Cr 26-28%, Fe ≥39%, Mo 3-4%, Cu 0.6-1.4%	Resists hot sulfuric acid, chloride SCC	Sulfuric acid concentrators, pickling tanks
Incoloy 31	N08031	Ni 30-32%, Cr 26-28%, Fe ≥45%, Mo 6-7%, Cu 1.0-1.4%, N 0.15-0.25%	Balanced oxidation/reduction resistance, high ductility	Pulp/paper digesters, pollution control systems
Incoloy 330	N08330	Ni 34-37%, Cr 17-20%, Fe ≥42%, Si 1-2%, Mn 1-2%	Thermal cycling resistance, low creep at 1150°C	Industrial furnace muffles, burner nozzles

Does INCOLOY 800 Rust?

Incoloy 800 exhibits excellent resistance to high-temperature oxidation but limited resistance to aqueous corrosion environments. The alloy forms protective chromium oxide scales at elevated temperatures, preventing further oxidation and maintaining structural integrity.

In atmospheric conditions at room temperature, Incoloy 800 demonstrates good corrosion resistance comparable to austenitic stainless steels. However, exposure to chloride-containing environments may result in localized corrosion attack.

We observe that the alloy's corrosion resistance decreases significantly in acidic aqueous solutions, particularly those containing chlorides. For such applications, we recommend considering Incoloy 825 or other corrosion-resistant alternatives.

The formation of protective oxide scales at high temperatures represents the primary corrosion protection mechanism. These scales must remain adherent and non-spalling to maintain protection during thermal cycling.

Is Incoloy 800 Better than 825?

The superiority of Incoloy 800 versus 825 depends entirely on application requirements and operating conditions.

For high-temperature applications above 1000°F (538°C), Incoloy 800 provides superior performance with its exceptional oxidation resistance and thermal stability. The alloy maintains strength and ductility at temperatures where Incoloy 825 begins to lose effectiveness.

In aqueous corrosive environments, particularly those containing chlorides or acids, Incoloy 825 demonstrates clear superiority. The addition of copper and molybdenum in 825 provides enhanced corrosion resistance that 800 cannot match.

Cost considerations favor Incoloy 800 due to its lower nickel content and absence of expensive alloying elements like molybdenum and copper. This economic advantage becomes significant in large-scale applications.

We recommend Incoloy 800 for high-temperature structural applications and Incoloy 825 for corrosive environment service. The decision should be based on the most critical performance requirement for each specific application.

Global Market Pricing Analysis 2025

Current worldwide pricing for Incoloy 800 reflects regional market conditions and supply chain factors:

Geographic Region	Price Range (USD/kg)	Market Characteristics
North America	$18-28	Domestic production, stable supply
European Union	$20-30	Regulatory compliance costs, quality premium
Asia-Pacific	$16-26	Manufacturing center, competitive pricing
Middle East	$19-29	Energy sector demand, import dependency
Latin America	$17-27	Resource availability, currency impacts
Africa	$21-31	Import logistics, limited local supply

Price variations reflect product form, order quantity, delivery terms, and specific grade requirements. Long-term supply agreements typically secure more favorable pricing structures.

Key Advantages of Incoloy 800

The distinctive benefits of Incoloy 800 make it preferred for high-temperature applications:

Exceptional High-Temperature Strength: Maintains mechanical properties at temperatures up to 2100°F (1149°C), surpassing most conventional alloys.

Outstanding Oxidation Resistance: Forms protective chromium oxide scales that prevent further oxidation during extended high-temperature exposure.

Thermal Shock Resistance: Withstands rapid temperature changes without cracking or distortion, crucial for cyclic heating applications.

Cost-Effective Performance: Provides high-temperature capability at lower cost than many alternative superalloys.

Excellent Fabricability: Standard metalworking techniques apply without special precautions or complex processing requirements.

Metallurgical Stability: Resists harmful phase transformations during long-term elevated temperature service.

Versatile Product Forms: Available in various configurations including sheets, plates, bars, tubes, and forgings.

Manufacturing Process Technology

The production of Incoloy 800 involves sophisticated metallurgical processing to achieve optimal properties:

Primary Melting: Electric arc furnace melting combines raw materials under controlled atmospheric conditions to achieve precise composition.

Secondary Refining: Argon oxygen decarburization (AOD) or vacuum oxygen decarburization (VOD) removes impurities and adjusts final composition.

Casting Operations: Continuous casting or ingot casting produces semi-finished forms with controlled solidification structure.

Hot Working: Initial breakdown rolling or forging at 2000-2150°F (1093-1177°C) develops proper grain structure and eliminates casting defects.

Intermediate Processing: Multiple hot rolling passes reduce thickness while maintaining temperature above 1800°F (982°C) to prevent work hardening.

Solution Treatment: Heat treatment at 2000-2100°F (1093-1149°C) followed by rapid cooling optimizes grain structure and mechanical properties.

Cold Finishing: Final cold rolling or drawing achieves precise dimensions and surface finish requirements.

Quality Control: Comprehensive testing including chemical analysis, mechanical testing, and microstructural examination ensures specification compliance.

French Nuclear Industry Procurement Case Study

Électricité de France (EDF) required high-performance tubing for steam generator replacement at their Gravelines Nuclear Power Station. The project demanded materials capable of withstanding high-temperature pressurized water reactor conditions while maintaining structural integrity over extended service life.

Project Specifications:

• 12,000 meters of seamless tubing in multiple diameters
• Operating conditions: 315°C (599°F) and 155 bar pressure
• Design life requirement: 40 years
• Nuclear grade quality assurance
• Full traceability documentation required

Technical Challenges: The original specification called for conventional austenitic stainless steel, but thermal analysis indicated potential creep concerns. We recommended Incoloy 800 based on its superior high-temperature creep resistance and proven nuclear service history.

Procurement Implementation: Total project value: €4.2 million Manufacturing timeline: 20 weeks Quality requirements: 100% eddy current testing, hydrostatic pressure testing Installation schedule: 2024 maintenance outage

Performance Validation: Post-installation inspection after six months of operation showed excellent performance with no indication of creep deformation or stress corrosion cracking. EDF projects 25% longer service life compared to previous materials, representing significant operational savings.

The success of this installation has led to specification of Incoloy 800 for additional steam generator projects across the French nuclear fleet.

Frequently Asked Questions

1. What is the maximum continuous operating temperature for Incoloy 800?

Incoloy 800 can operate continuously at temperatures up to 2100°F (1149°C) in oxidizing atmospheres. For intermittent service, the alloy can withstand temperatures up to 2200°F (1204°C). At these extreme temperatures, we recommend periodic inspection to monitor scale formation and ensure continued structural integrity.

2. Can Incoloy 800 be welded using standard procedures?

Yes, Incoloy 800 exhibits excellent weldability using conventional fusion welding processes including GTAW, GMAW, and SMAW. No preheating is required for most applications. We recommend using ER NiCr-3 or equivalent filler metals to maintain optimal properties in the weld metal and heat-affected zone.

3. How does Incoloy 800 perform in carburizing atmospheres?

Incoloy 800 demonstrates outstanding resistance to carburization due to its chromium content and protective oxide scale formation. The alloy maintains its mechanical properties even after prolonged exposure to carbon-rich atmospheres at elevated temperatures, making it ideal for heat treatment furnace applications.

4. What post-fabrication heat treatment is recommended?

We recommend solution annealing at 2000-2100°F (1093-1149°C) followed by rapid air cooling or water quenching. This treatment optimizes grain structure, relieves fabrication stresses, and ensures maximum high-temperature performance. Slower cooling rates may result in carbide precipitation and reduced ductility.

5. How does thermal cycling affect Incoloy 800 performance?

Incoloy 800 exhibits excellent thermal fatigue resistance due to its low coefficient of thermal expansion and high thermal conductivity. The alloy can withstand numerous heating and cooling cycles without significant degradation in mechanical properties. However, we recommend periodic inspection in severe thermal cycling applications to monitor for any signs of thermal fatigue cracking.

Technical References and Standards

• ASTM B407 - Standard Specification for Ni-Fe-Cr Alloy Seamless Pipe and Tube
• ASME SB-407 - Specification for Nickel-Iron-Chromium Alloy Seamless Pipe and Tube
• ASTM B408 - Standard Specification for Ni-Fe-Cr Alloy Plate, Sheet, and Strip
• ISO 15156 - Petroleum and Natural Gas Industries - Materials for Use in H₂S-Containing Environments
• Wikipedia - Heat-Resistant Alloy Classifications and Applications
